Industrial Box knockout 175x105x80

Commercialized

Item number

CSU08430000

Local code: *

GTIN: 8712186037580

Description: Industrial Box knockout 175x105x80

Wibe Group. CSU08430000 - Stago - c profile - 30x30 mm - L=6m - steel - hot-dip galvanized

Data Sheet

Product status

Commercialized

Short description

Industrial Box knockout 175x105x80

Medium description

Stago - c profile - 30x30 mm - L=6m - steel - hot-dip galvanized

Material

Steel

Material type or surface treatment

Hot-dip galvanized

Environmental corrosion class

C2; C3; C4

Activity

Cable support systems

Product family

Support system

Brand

Stago

GTIN

8712186037580

Length (EF001438)

* mm

Width (EF000008)

30 mm

Height (EF000040)

30 mm

Slit width (EF005247)

14 mm

Material thickness (EF000386)

2.5 mm

Profile shape (EF005179)

C-profile

Model (EF000010)

Singular profile

Type of perforation (EF004147)

None

Hole width (EF005742)

* mm

With toothing (EF000571)

Snap (EF007562)

Load bearing capacity (EF002918)

* kN

Area moment of inertia Iy (EF012513)

* cm4

Area of inertia Iz (EF012514)

* cm4

Moment of resistance Wy (EF012503)

* cm³

Moment of resistance Wz (EF012504)

* cm³

Suitable for circuit integrity (EF007806)

Material (EF002169)

Steel

Material quality (EF001257)

Other

Surface protection (EF000139)

Layer thickness surface protection (EF025871)

* µm

Colour (EF000007)

RAL (EF000116)

Weight (EF000167)

* kg/m

Weight pack 1

1.54 kg

Length pack 1

1000 mm

Width pack 1

30 mm

Height pack 1

30 mm

Customs code

7308909800

Net weight

9.24 kg

Country of origin

ETIM class

EC000386

Environmental Documents

Item number

CSU08430000

Local code: *

GTIN: 8712186037580

Description: Industrial Box knockout 175x105x80

Data Sheet

Corrosion class		C1	C2	C3	C4	C5	CX
Environmental corrosion		Very low	Low	Average	High	Very high	Extreme
Examples of environments	Indoors	Heated areas with arid atmosphere and insignificant quantities of pollutant, e.g. offices, shops, schools and hotels.	Non-heated areas with fluctuating levels of temperature and humidity. Few instances of condensation and low levels of airborne pollution, e.g. sports halls and warehouses.	Average levels of humidity and some airborne pollution resulting from production processes, e.g. breweries, dairies, laundries.	High humidity and considerable airborne pollution as the result of production processes, e.g. chemical plants, swimming pools and dockyards.	Buildings with almost permanent condensation and with high pollution	Industrial buildings with extreme humidity and aggressive atmosphere.
Examples of environments	Outdoors		Atmospheres with low levels of airborne pollution. Rural areas.	Atmospheres containing some salt or average levels of air-borne pollution. Urban and light industrial areas. Areas affected by coastal conditions.	Atmospheres with average salt content or discernible levels of airborne pollution. Industrial and coastal areas.	Industrial areas with high humidity and aggressive atmosphere, and coastal areas with high salinity	Offshore areas with high salinity, industrial areas with extreme humidity, and aggressive atmospheres, sub-tropical or tropical atmospheres.
Wibe Group designation Exceeds requirements. Extremely high durability. Recommended very high durability ( >20 years) Possible alternative. High durability (10-20 years)	Electro-galvanized (EG)
	Pre-galvanized (PG)
	Zinc+ (Z+)
	Hot-dip galvanized (HDG)
	Zinkpox (ZP)
	Stainless steel AISI 304L(SS304)
	Stainless steel AISI 316L (SS316)
	Glass Fibre Reinforced Polymer (FRP/GRP)
