Vertical wall piece 200-120 R9016

/storage/1C704768DC0195C0F7AD8534DFB7E75C53798A535731A688E7187B53ACF9A7EB/9df6751229b7467793cf4a226a34f1c2/jpg/media/b7e01d5ecae642cba54a3d4f89164f89/CSU0872349916.jpg
Commercialized

Item number

CSU0872349916

Local code: *
GTIN: 8712186110306
Description: Vertical wall piece 200-120 R9016

Environmental corrosion class

Wibe Group. CSU0872349916 - Stago - vertical wall piece formed 60x200-120mm pre-galvanized R9016

Properties

Status product
Product status
Commercialized
Commercial and Web
Short description
Vertical wall piece 200-120 R9016
Medium description
Stago - vertical wall piece formed 60x200-120mm pre-galvanized R9016
Material
Steel
Material type or surface treatment
Painted
Environmental corrosion class
C2
Base
Activity
Cable support systems
Product family
Cable trays
Brand
Stago
GTIN
8712186110306
ETIM (EC001544-Tee for cable tray)
Cable tray height (EF004822)
60 mm
Cable tray width (EF004820)
200 mm
Construction type (EF000767)
T-piece vertical falling along
Inner radius (EF004793)
100 mm
NATO (EF006059)
No
Model (EF000010)
Without connector
Wide span model (EF006397)
No
Suitable for circuit integrity (EF007806)
No
Material (EF002169)
Steel
Stainless steel, pickled (EF006388)
No
Material quality (EF001257)
Other
Surface protection (EF000139)
Continuously galvanized and coated
Colour (EF000007)
White
RAL (EF000116)
9016
Logistic
Weight pack 1
2.266 kg
Length pack 1
521 mm
Width pack 1
261 mm
Height pack 1
203 mm
Customs code
7308909800
Net weight
2.27 kg
Certification
ETIM class
EC001544
Environmental
GWP Total A1-A3
9.087 kgCO2e

Item number

CSU0872349916

Local code: *
GTIN: 8712186110306
Description: Vertical wall piece 200-120 R9016

Environmental corrosion class

Corrosion class C1 C2 C3 C4 C5 CX
Environmental corrosion Very low Low Average High Very high Extreme
Examples of environments Indoors Heated areas with arid atmosphere and insignificant quantities of pollutant, e.g. offices, shops, schools and hotels. Non-heated areas with fluctuating levels of temperature and humidity. Few instances of condensation and low levels of airborne pollution, e.g. sports halls and warehouses. Average levels of humidity and some airborne pollution resulting from production processes, e.g. breweries, dairies, laundries. High humidity and considerable airborne pollution as the result of production processes, e.g. chemical plants, swimming pools and dockyards. Buildings with almost permanent condensation and with high pollution Industrial buildings with extreme humidity and aggressive atmosphere.
Outdoors   Atmospheres with low levels of airborne pollution. Rural areas. Atmospheres containing some salt or average levels of air-borne pollution. Urban and light industrial areas. Areas affected by coastal conditions. Atmospheres with average salt content or discernible levels of airborne pollution. Industrial and coastal areas. Industrial areas with high humidity and aggressive atmosphere, and coastal areas with high salinity Offshore areas with high salinity, industrial areas with extreme humidity, and aggressive atmospheres, sub-tropical or tropical atmospheres.
Wibe Group designation

Exceeds requirements. Extremely high durability.

Recommended very high durability ( >20 years)






Possible alternative. High durability (10-20 years)
Electro-galvanized (EG)






Pre-galvanized (PG)







Zinc+ (Z+)





Hot-dip galvanized (HDG)









Zinkpox (ZP)









Stainless steel AISI 304L(SS304)









Stainless steel AISI 316L (SS316)






Glass Fibre Reinforced Polymer (FRP/GRP)







This table shows estimated values.
For more detailed advice, please contact technical support at Wibe Group
