Rising piece 250 R9016/70
Commercialized
Item number
CSU0864409916
Local code:
*
GTIN:
8712186116100
Description:
Rising piece 250 R9016/70
Wibe Group. CSU0864409916 - Stago - internal riser formed - 60x250 mm - steel - pre-galvanized - RAL9016
Properties
Status product
Product status
Commercialized
Commercial and Web
Short description
Rising piece 250 R9016/70
Medium description
Stago - internal riser formed - 60x250 mm - steel - pre-galvanized - RAL9016
Width
250 mm
Material
Steel
Material type or surface treatment
Painted
Corrosion class
C2
Base
Activity
Cable support systems
Product family
Cable trays
Brand
Stago
GTIN
8712186116100
ETIM (EC002400-Bend for cable tray)
Change of direction (EF005210)
Vertically rising
Angle (EF001218)
90°
Construction type (EF000767)
Bend rigid
Bend model (EF020423)
Smooth bend
With cover (EF007965)
No
Inner radius (EF004793)
180 mm
Cable tray height (EF004822)
60 mm
Cable tray width (EF004820)
250 mm
Material thickness (EF000386)
1 mm
Side wall perforation (EF001122)
No
Mounting perforation in bottom (EF004545)
No
NATO (EF006059)
No
Model (EF000010)
Without connector
Wide span model (EF006397)
No
Suitable for circuit integrity (EF007806)
No
Material (EF002169)
Steel
Stainless steel, pickled (EF006388)
No
Material quality (EF001257)
Other
Surface protection (EF000139)
Continuously galvanized and coated
Colour (EF000007)
White
RAL (EF000116)
9016
Logistic
Quantity pack 1
1
Weight pack 1
1.504 kg
Length pack 1
284 mm
Width pack 1
284 mm
Height pack 1
253 mm
GTIN pack 1
8712186116100
Customs code
7308909800
Net weight
1.5 kg
Certification
ETIM class
EC002400
