KB284 Reinforced 60x300 T=0.8 L=3m R9004
Commercialized
Item number
CSU2601302R904
Local code:
*
GTIN:
*
Description:
KB284 Reinforced 60x300 T=0.8 L=3m R9004
Properties
Status product
Product status
Commercialized
Commercial and Web
Short description
KB284 Reinforced 60x300 T=0.8 L=3m R9004
Medium description
Stago - KB284 reinforced cable tray 60x300mm - T=0.8mm - L=3m - R9004
Length
3000 mm
Width
300 mm
Height
60 mm
Material
Steel
Material type or surface treatment
Painted
Environmental corrosion class
C2
Base
Activity
Cable support systems
Product family
Cable trays
Brand
Stago
Range
KB284
ETIM (EC000047-Cable tray/wide span cable tray)
Height (EF000040)
60 mm
Width (EF000008)
300 mm
Material thickness (EF000386)
0.8 mm
Length (EF001438)
3000 mm
Useful cross section (EF005140)
18000 mm²
With cover (EF007965)
No
Side wall perforation (EF001122)
Yes
Mounting perforation in bottom (EF004545)
Yes
NATO (EF006059)
No
Model (EF000010)
Without connector
Wide span model (EF006397)
*
Suitable for circuit integrity (EF007806)
No
Material (EF002169)
Steel
Stainless steel, pickled (EF006388)
*
Material quality (EF001257)
Other
Surface protection (EF000139)
Continuously galvanized and coated
Colour (EF000007)
Black
RAL (EF000116)
9004
Weight (EF000167)
2.43 kg/m
Max. safe working load according to IEC 61537 (EF016305)
* N/m
Span between supports according to IEC 61537 (EF015363)
* mm
Load test type according to IEC 61537 (EF015362)
Type I
Logistic
Pack 1 type
Each
Quantity pack 1
1
Weight pack 1
7.28 kg
Length pack 1
3000 mm
Width pack 1
300 mm
Height pack 1
60 mm
Customs code
7308909800
Net weight
7.28 kg
Country of origin
NL
Certification
ETIM class
EC000047
Environmental
GWP Total A1-A3
29.177 kgCO2e
