Installation systems

One single solution solved in one go


Our entire installation system has been designed with ease of use and ease of installation in mind. The solution adheres to industry standards, and we use the highest grade and the most sustainable materials available. We have designed a fully integrated system that will be launched over time. Having an optimized number of well-designed and smarter parts means simplifying the procurement, planning and installation process for any building project.

Trunking

Wiring devices

Product 1 - 21 of 466 products
Corrosion class C1 C2 C3 C4 C5 CX
Environmental corrosion Very low Low Average High Very high Extreme
Examples of environments Indoors Heated areas with arid atmosphere and insignificant quantities of pollutant, e.g. offices, shops, schools and hotels. Non-heated areas with fluctuating levels of temperature and humidity. Few instances of condensation and low levels of airborne pollution, e.g. sports halls and warehouses. Average levels of humidity and some airborne pollution resulting from production processes, e.g. breweries, dairies, laundries. High humidity and considerable airborne pollution as the result of production processes, e.g. chemical plants, swimming pools and dockyards. Buildings with almost permanent condensation and with high pollution Industrial buildings with extreme humidity and aggressive atmosphere.
Outdoors   Atmospheres with low levels of airborne pollution. Rural areas. Atmospheres containing some salt or average levels of air-borne pollution. Urban and light industrial areas. Areas affected by coastal conditions. Atmospheres with average salt content or discernible levels of airborne pollution. Industrial and coastal areas. Industrial areas with high humidity and aggressive atmosphere, and coastal areas with high salinity Offshore areas with high salinity, industrial areas with extreme humidity, and aggressive atmospheres, sub-tropical or tropical atmospheres.
Wibe Group designation

Exceeds requirements. Extremely high durability.

Recommended very high durability ( >20 years)






Possible alternative. High durability (10-20 years)
 Electro-galvanized (EG)






Pre-galvanized (PG)







Zinc+ (Z+)





Hot-dip galvanized (HDG)









Zinkpox (ZP)









Stainless steel AISI 304L(SS304)









Stainless steel AISI 316L (SS316)






Glass Fibre Reinforced Polymer (FRP/GRP)







This table shows estimated values.
For more detailed advice, please contact technical support at Wibe Group
